Custom XLR 3-Pin Female to Molex 51163-0300 Cable Assembly
| Neutrik NC3FXX | 20AWG UL2464
Custom XLR 3-Pin Female to Molex 51163-0300 Cable Assembly:
This custom-built XLR 3-Pin Female to Molex Mini-Lock 3-Pin Cable Assembly is designed for
professional audio, industrial control, and signal transmission applications.
Using a genuine Neutrik NC3FXX XLR connector and Molex 51163-0300 housing with TPA
retainer, this cable provides high mechanical durability, secure locking, and low-noise signal
performance.
The cable is constructed with UL2464 20AWG stranded conductors, ensuring excellent
conductivity, flexibility, and safety compliance. Each assembly undergoes 100% electrical
testing for continuity, insulation resistance, and short-circuit prevention, guaranteeing flawless
performance in demanding environments.
Key Features
Neutrik NC3FXX XLR 3-Pin Female — industry-standard, durable, secure locking
Molex 51163-0300 Mini-Lock 3-Pin Housing — compact & vibration resistant
With Molex TPA (0511640305) — ensures terminal retention & anti-back-out safety
UL2464 20AWG cable, OD 6.6mm — stable signal transmission
Customized length available (300mm ~ 10m)
100% continuity, open/short, intermit test performed
RoHS 2.0 compliant
Technical Specifications Table
| Item | Specification | Details / Source |
|---|---|---|
| Product Name | XLR Female to Molex 3-Pin Cable Assembly | Customizable |
| XLR Connector (P1) | Neutrik NC3FXX | 3-Pin XLR Female |
| Molex Connector (P2) | Molex 51163-0300 | Mini-Lock 2.50mm Pitch, 3-pin |
| TPA Retainer | Molex 0511640305 | Anti-back-out design |
| Cable Type | UL2464 20AWG × 3C | OD 6.6mm, PVC black |
| Length | 700mm ±10mm | Custom lengths available |
| Pin Assignment | P1: 1-2-3 → P2: 1-2-3 | Color: White / Green / Brown |
| Electrical Test | 100% Open/Short/Intermittence Test | Per drawing requirements |
| Conductor Resistance | ≤ 2Ω Max | Verified |
| Insulation Resistance | ≥ 10MΩ @ 300V DC | 10ms minimum |
| Temperature Rating | 80°C | UL2464 spec |
| Voltage Rating | 300V | UL2464 spec |
| Compliance | RoHS 2.0 | Environment-safe |
Application Areas
This cable assembly is widely used in:
Professional Audio Equipment
Mixers, amplifiers, microphones
Stage & lighting control systems
AV integration systems
Broadcasting & Media Systems
Camera power/control adapters
Field recording equipment
Signal routing panels
Industrial & Automation Systems
Sensor and control signal lines
Testing & measuring devices
OEM equipment wiring harnesses
Customization Options
We provide full customization to meet OEM/ODM needs:
Cable Options
Length: 100mm – 10m
Wire gauge: 20AWG / 22AWG / 24AWG
Jacket: PVC / TPU / TPE
Color: Black / Gray / Custom
Connector Options
XLR Male / Female / 4-Pin / 5-Pin
Molex Mini-Lock / Micro-Fit / Ultra-Fit
Custom terminal crimping
Additional Services
Labeling & serial number printing
Over-molding
Braiding & shielding
Waterproofing (IP67 housing available)
Quality Assurance
Every cable is manufactured under a strict quality management system:
100% electrical testing
Pull-force & retention testing
Crimp-height inspection
Visual QC for molding & termination
ROHS 2.0 compliance
Q1. Is it a factory?
A: Yes, we are a factory with more than 16 years of design and manufacturing experience.
Q2. Is there any certification?
A: Yes, we have ISO9001, ISO14001, TS16949, ISO13485, and UL certifications.
Q3. What is your specialty?
A: We can design products according to the application requirements.
Q4. Do you accept OEM/ODM orders?
A: Yes, we accept OEM and ODM orders. For OEM orders, the MOQ is 100 pcs. For ODM
orders, the MOQ is 1000 pcs. A mold fee will be charged depending on the design.
Q5. How long does it take to complete an order?
A:For small orders and products in stock, preparation and delivery take less than 3 days.
Shipping time depends on the chosen method—fastest 7 days, longest 1 month.For large
orders, material preparation takes 5–21 working days depending on quantity, testing 1–3
working days, and packing 1 day. The fastest lead time is 7 days, and the longest is 25 days,
excluding shipping.
Q6. What additional services can long-term clients get?
A:New products will be offered together with orders, allowing you to test their market potential
and sell them in your district.Additional fee discounts and lower prices for smaller-quantity
purchases.Support with promotional images, including adding your logo.
Q7. How long is the warranty, and how do you protect customers in case of defects?
A: All cables come with a 12–36 month warranty. For large orders, we provide 0.3%–0.5%
extra backup units. For example, ordering 1000 pcs will include 1003 pcs.If you receive more
than 5 faulty pcs and the defect rate is below 0.1%, please contact our sales team with photos.
We will replace the goods in your next order or issue a refund.
Q8. Do you accept free sample orders?
A: Yes, sample orders are supported. Some samples can be provided free of charge (shipping
cost not included).
How to contact us?
Send your inquiry details below and click “Send” now!
Free samples and the best price are waiting for you.
If you cannot find a product on our website, feel free to contact us — even if we don’t produce it,
we can help you source the same item with good quality and price.
